FUEL -- Fuel System Monitor

CCM -- Comprehensive Component Monitor

EGR – EGR System Monitor

HCCAT -- NMHC Catalyst Monitor

NCAT -- NOx Aftertreatment Monitor

BP -- Boost Pressure System Monitor

EGS -- Exhaust Gas Sensor Monitor

PM -- PM Filter Monitor
Figure 6.22
5) If the vehicle supports readiness test of “This Drive Cycle”, a
screen of the following displays: (Figure 6.23)
Figure 6.23
6) Use the UP/DOWN scroll button for more PIDs if additional
information is available on more than one page. Or use the
LEFT/RIGHT scroll button to view PIDs in the previous/next
page.
Since DTCs cleared
MIL Status OFF
Misfire Monitoring N/A
Fuel system monitoring OK
Comprehensive
component monitoring OK
Catalyst monitoring N/A
Heated catalyst monitor N/A
This Drive Cycle
MIL Status OFF
Misfire Monitoring N/A
Fuel system monitoring OK
Comprehensive
component monitoring OK
Catalyst monitoring N/A
Heated catalyst monitor N/A
