Figure 5.28 – Autel MaxiDiag Elite MD701 User Manual
Page 34

32
Figure 5.28
The three keyboard function buttons work as below.
[One Graphic]: To view the live data waveform.
[Save]: Save the live data.
[Pause]: Suspend viewing and stop saving live data.
3) Press the Function button corresponding to One Graphic. The
screen will show the live data waveform as Figure 5.29.
Figure 5.29
4) Press the Function button corresponding to Two Graphic, the
screen will show two graphs as Figure 5.30.
Live Data
MFF_RPM(Engine RPM)
837
RPM
VEHICLE SPEED SENSOR
0
km/h
Pause ︱ one Graphic︱ Save
