19
5. Diagnostics
NOTE: The screens shown below in this chapter are examples.
The screens actually appear vary by vehicle.
5.1 Entering Vehicle Information
Before using the scan tool to diagnose, you must input the vehicle
information. There are generally three ways to input the vehicle
information.
Vehicle information manual acquisition.
VIN code automatic acquisition.
VIN code manual acquisition.
The way to enter diagnostic procedure depends on vehicle being
tested.
5.1.1 Vehicle Information Manual Acquisition
Follow these steps to enter the vehicle information and begin
diagnostics. (Taking Ford as an example)
1) Turn on the scan tool and wait for the Main Screen to appear.
2) Select Scan icon in the Main Screen (Figure 3.1) and wait for
the vehicle manufacturer screen. Choose the correct vehicle
make.
Figure 5.1
