labnotEbooK ™
A UniqUe Tool for DocUmenTATion AnD reporT GenerATion
the labnotebook feature of Wavesurfer MXs-b and Mso MXs-b provides a report generation
tool to save and document all your work. saving all displayed waveforms, relevant settings,
and screen images is all done through labnotebook, eliminating the need to navigate multiple
menus to save all these files independently.
The touch screen and stylus
allow for easy annotation
of the screen. LabNotebook allows
you to add freehand
text and graphics in multiple
colors along with printed
text and arrows to help identify
important parts of your
waveforms and measurements.
Annotated screen captures can
be included in custom reports.
V/div
T/div
Memory Length
Sample Rate
Measurement
Math
WaVEforM
osCillosCoPE sEt uP
sCrEEn DuMP
Print
Er
HarD DriVE
usb DriVE
EMail
D
ocum
ent You
r Work
One-touch Functionality Save Your Wo
rk Reca
ll Jobs
Easy report generation helps you
share your findings and communicate
important results.
LabNotebook adds a simple way to
report your work and save all essential
waveforms, settings, and screen images.
Quickly save all the
necessary files with
LabNotebook in a
single button press.
Recall your settings
from any report
by using the
Flashback capability.
