10
sPECifiCations
Wavesurfer Wavesurfer Wavesurfer Wavesurfer Wavesurfer Wavesurfer
analog Channels 24MXs-b 44MXs-b 42MXs-b 64MXs-b 62MXs-b 104MXs-b
– Vertical Mso 44MXs-b Mso 64MXs-b Mso 104MXs-b
Bandwidth (@ 50 Ω) 200 MHz 400 MHz 400 MHz 600 MHz 600 MHz 1 GHz
Rise Time 1.75 ns 875 ps 875 ps 525 ps 525 ps 350 ps
Input Channels 4 4 2 4 2 4
Vertical Resolution 8 bits
Vertical Sensitivity (V/div) 2 mV/div–10 V/div (1 M Ω); 2 mV/div–1 V/div (50 Ω)
Vertical (DC Gain) ±1.0% of full scale (typical); ±1.5% of full scale ≥ 10 mV/div (warranted)
Accuracy
BW Limit
20 MHz 20 MHz, 200 MHz
Maximum Input Voltage 50 Ω: 5 V
rms
, 1 M Ω: 400 V max. (DC + Peak AC ≤ 5 kHz) 50 Ω: 5 Vrms
1 M Ω: 250 V max.
(DC + Peak AC
≤10 kHz)
Input Coupling AC, DC, GND (DC and GND for 50 Ω)
Input Impedance 1 M Ω || 16 pF, or 50 Ω
analog Channels
– acquisition
Sample Rate 2.5 GS/s 5 GS/s 5 GS/s
(Single-shot) (10 GS/s Interleaved)
Sample Rate 50 GS/s
(Repetitive)
Record Length
16 Mpts/Ch (all channels), 32 Mpts (interleaved)
Capture Time Up to 3.2 ms at full sample rate on all four channels
Acquisition Modes Real Time, Roll, RIS (Random Interleaved Sampling), WaveStream (Fast Viewing Mode), Sequence (Segmented Memory
up to 5,000 segments with 1μ s intersegment time)
Time Base Range 200 ps/div–1000 s/div (roll mode from 500 ms/div–1000 s/div)
Time Base Accuracy ≤ 5 ppm @ 25 °C (typical) ( ≤ 10 ppm @ 5–40 °C)
Digital Channels
– Vertical
Input Channels 18 (D0–D17) 18 (D0–D17) 18 (D0–D17)
Input Impedance 100 k Ω || 5.0 pF 100 k Ω || 5.0 pF 100 k Ω || 5.0 pF
Maximum Input Voltage ±30 V non-destruct ±30 V non-destruct ±30 V non-destruct
Threshold Groupings D0–D8, D9–D17 D0–D8, D9–D17 D0–D8, D9–D17
Threshold Selections TTL, ECL, CMOS, TTL, ECL, CMOS, TTL, ECL, CMOS,
PECL, LVDS, PECL, LVDS, PECL, LVDS,
User Defined User Defined User Defined
Digital Channels
– acquisition
Sample Rate 1 GS/s 1 GS/s 1 GS/s
Record Length 10 Mpts/Ch 10 Mpts/Ch 10 Mpts/Ch
Minimum Detectable 2 ns 2 ns 2 ns
Pulse Width
Maximum Input
250 MHz 250 MHz 250 MHz
Frequency
