11
sPECifiCations
Wavesurfer Wavesurfer Wavesurfer Wavesurfer Wavesurfer Wavesurfer
24MXs-b 44MXs-b 42MXs-b 64MXs-b 62MXs-b 104MXs-b
trigger system Mso 44MXs-b Mso 64MXs-b Mso 104MXs-b
Trigger Modes Normal, Auto, Single, and Stop
Trigger Sources Any input channel, External, Ext/10, or line; slope and level unique to each source (except for line trigger)
Trigger Coupling DC, AC, HFRej, LFRej
Pre-trigger Delay 0–100% of full scale
Post-trigger Delay 0–10,000 divisions
Trigger Hold-off 1 ns to 20 s or 1 to 1,000,000,000 events
Internal Trigger ±4.1 div from center
Level Range
External Trigger Range
EXT/10 ±4V; EXT ±400 mV
Trigger Types Edge, Glitch, Width, Logic (Pattern), TV (NTSC, PAL, SECAM, HDTV–720p, 1080i, 1080p), Runt, Slew Rate, Interval
(signal or Pattern), Dropout, Qualified (State or Edge)
Probes
Standard Probes One PP009 (5 mm) per channel One PP011 (5 mm)
per channel
Probing System BNC and LeCroy ProBus for Active voltage, current and differential probes
Measure, Zoom, and Math tools
Measurement Up to 6 of the following parameters can be calculated at one time on any waveform: Amplitude, Area, Base (Low), Delay,
Parameters Duty, Fall Time (90%–10%), Fall Time (80%–20%), Frequency, Maximum, Mean, Minimum, Overshoot+, Overshoot-,
Period, Peak-Peak, Phase, Rise Time (10%–90%), Rise Time (20%–80%), RMS, Skew, Standard Deviation, Top (High),
Width+, Width-. Measurements can be gated.
Zooming Use front panel QuickZoom button, or use touch screen or mouse to draw a box around the zoom area.
Math Functions Functions include Sum, Difference, Product, Ratio, Absolute Value, Averaging (summed and continuous), Derivative,
Envelope, Enhanced Resolution (to 11-bits), Floor, Integral, Invert, Reciprocal, Rescale (change scale and units), Roof,
Square, Square Root and FFT (up to 1 Mpts with power spectrum output and rectangular, VonHann, and FlatTop
windows). 1 math function may be defined at a time, 2 functions may be chained together.
Display system
Display Type Color, 10.4” TFT-LCD Touch Screen
Display Resolution SVGA: 800 x 600 pixels
Connectivity
Ethernet Port 10/100/1000Base-T Ethernet interface (RJ-45 connector)
USB Ports (5) USB Ports
GPIB Port (Optional) Supports IEEE – 488.2
External Monitor Port Standard 15-pin D-Type SVGA-compatible DB-15 connector
Remote Control Via Windows Automation, or via LeCroy Remote Command Set
Network Communication VXI-11 or VICP, LXI Class C Compliant
Standard
Physical
Dimensions (HWD) 260 mm x 340 mm x 152 mm Excluding accessories and projections (10.25” x 13.4” x 6”)
Net Weight 7.26 kg. (16.0 lbs.)
