orDEring inforMation
Product Description Product Code
Wavesurfer MXs-b oscilloscopes
200 MHz, 2.5 GS/s, 4 Ch, 16 Mpts/Ch DSO WaveSurfer 24MXs-B
with 10.4” Color Touch Screen Display.
32 Mpts Interleaved
400 MHz, 5 GS/s, 2 Ch, 16 Mpts/Ch DSO
WaveSurfer 42MXs-B
with 10.4” Color Touch Screen Display.
32 Mpts Interleaved
400 MHz, 5 GS/s, 4 Ch, 16 Mpts/Ch DSO
WaveSurfer 44MXs-B
with 10.4” Color Touch Screen Display.
32 Mpts Interleaved
600 MHz,5 GS/s, 2 Ch, 16 Mpts/Ch DSO
WaveSurfer 62MXs-B
with 10.4” Color Touch Screen Display.
10 GS/s, 32 Mpts Interleaved
600 MHz,5 GS/s, 4 Ch, 16 Mpts/Ch DSO
WaveSurfer 64MXs-B
with 10.4” Color Touch Screen Display.
10 GS/s, 32 Mpts Interleaved
1 GHz, 5 GS/s, 4 Ch, 16 Mpts/Ch DSO
WaveSurfer 104MXs-B
with 10.4” Color Touch Screen Display.
10 GS/s, 32 Mpts Interleaved
Mso MXs-b Mixed signal oscilloscopes
400 MHz, 5 GS/s, 4+18 Ch, 16 Mpts/Ch MSO with MSO 44MXs-B
10.4” Color Touch Screen Display. 32 Mpts Interleaved
600 MHz, 5 GS/s, 4+18 Ch, 16 Mpts/Ch MSO
MSO 64MXs-B
with 10.4” Color Touch Screen Display.
10 GS/s, 32 Mpts Interleaved
1 GHz, 5 GS/s, 4+18 Ch, 16 Mpts/Ch MSO
MSO 104MXs-B
with 10.4” Color Touch Screen Display.
10 GS/s, 32 Mpts Interleaved
included with standard Configuration
(Wavesurfer MXs-b and Mso MXs-b)
÷10, 500 MHz, 10 M Ω Passive Probe (Total of 1 Per Channel), Getting Started
Manual and Quick Reference Guide, Standard Ports: Ethernet, USB 2.0 (5),
SVGA Video Out, Audio In/Out, Protective Front Cover, Anti-virus Software
(Trial Version), Standard Commercial Calibration and Performance Certificate,
3-year Warranty
included with Mso MXs-b
MS-250 Mixed Signal Oscilloscope Module, 18 Channel Digital Lead Set,
LeCroy Bus and USB2.0 Cables (1.3 m), Ground Extenders (Qty. 20), Flexible
Ground Leads (Qty. 5), Carrying Case, Operator’s Manual and Quick Refer-
ence Guide
general accessories
Keyboard Accessory WSXs-KYBD
Optical Mouse Accessory WSXs-MOUSE
External GPIB Accessory USB2-GPIB
Hard Carrying Case WSXs-HARDCASE
Soft Carrying Case WSXs-SOFTCASE
Rack Mount Accessory WSXs-RACK
Accessory Pouch WSXs-POUCH
Mounting accessory
Clamp Mounting Stand WSXs-MS-CLAMP
local language overlays
German Front Panel Overlay WSXs-A-FP-GERMAN
French Front Panel Overlay WSXs-A-FP-FRENCH
Italian Front Panel Overlay WSXs-A-FP-ITALIAN
Spanish Front Panel Overlay WSXs-A-FP-SPANISH
Japanese Front Panel Overlay WSXs-A-FP-JAPANESE
Korean Front Panel Overlay WSXs-A-FP-KOREAN
Chinese (Tr) Front Panel Overlay WSXs-A-FP-CHNES-TR
Chinese (Simp) Front Panel Overlay WSXs-A-FP-CHNES-SI
Russian Front Panel Overlay WSXs-A-FP-RUSSIAN
Product Description Product Code
serial Data options
I 2 C, SPI and UART Trigger and Decode Option WSXs-EMB
I 2 C Bus Trigger and Decode Option WSXs-I2Cbus TD
UART and RS-232 Trigger and Decode Option WSXs-UART-RS232bus TD
CAN, LIN and FlexRay Trigger and Decode Option
WSXs-AUTO
SPI Bus Trigger and Decode Option WSXs-SPIbus TD
LIN Trigger and Decode Option WSXs-LINbus TD
CAN TD Trigger and Decode Option WSXs-CANbus TD
FlexRay Trigger and Decode Option WSXs-FlexRaybus TD
MIL-STD-1553 Trigger and Decode Option WSXs-1553 TD
ARINC 429 Symbolic Decode Option WSXs-ARINC429bus DSymbolic
USB 2.0 Decode Option WSXs-USB2bus D
USB2-HSIC Decode Option WSXs-USB2-HSICbus D
D-PHY Decode Option WSXs-DPHYbus D
DigRF 3G Decode Option WSXs-DigRF3Gbus D
DigRF v4 Decode Option WSXs-DigRFv4bus D
Audiobus Trigger and Decode Option WSXs-Audiobus TD
for I 2 S, LJ, RJ, and TDM
Mixed signal solutions
500 MHz, 18 Channels, 2 GS/s, 50 Mpts/ch Mixed MS-500
Signal Oscilloscope Option
250 MHz,36 Ch,1 GS/s,25 Mpts/ch (500MHz,18 Ch,2 GS/s,
MS-500-36
50 Mpts/ch Interleaved) Mixed Signal Option
250 MHz, 18 Channels, 1 GS/s, 10 Mpts/ch Mixed Signal
MS-250
Oscilloscope Option (included in all WaveRunner MSO models)
Mso MXs-b accessories
Large Gripper Probe Set for 0.10 Inch (2.54 mm) PK400-1
Pin Pitch. Includes 10 Probes with Color-coded Leads
Medium Gripper Probe Set for 0.04 Inch (1.0 mm)
PK400-2
Pin Pitch. Includes 10 Probes with Color-coded Leads
Small Gripper Probe Set for 0.008 Inch (0.2 mm)
PK400-3
Pin Pitch. Includes 10 Probes with Color-coded Leads
18-pin 3M Interface Cable MSO-3M
MSO-3M
(Mates with 3M Part Number 2520-6002)
36 Channel Mictor Connector
MSO-Mictor
(Includes 1 MSO-MICTOR-SHROUD)
Probes and amplifiers *
Set of 4 ZS1500, 1.5 GHz, 0.9 pF, 1 M Ω ZS1500-QUADPAK
High Impedance Active Probe
Set of 4 ZS1000, 1 GHz, 0.9 pF, 1 M
Ω ZS1000-QUADPAK
High Impedance Active Probe
200 MHz, 3.5 pF, 1 M
Ω Active Differential Probe ZD200
500 MHz, 1.0 pF, 1 M Ω Active Differential Probe ZD500
1 GHz, 1.0 pF, 1 M Ω Active Differential Probe ZD1000
1.5 GHz, 1.0 pF, 1 M Ω Active Differential Probe ZD1500
30 A; 100 MHz Current Probe – AC/DC; 30 A
rms
; 50 A
peak
Pulse CP031
30 A; 50 MHz Current Probe – AC/DC; 30 A
rms
; 50 A
peak
Pulse CP030
30 A; 50 MHz Current Probe – AC/DC; 30 A
rms
; 50 A
peak
Pulse AP015
150 A; 10 MHz Current Probe – AC/DC; 150 A
rms
; 500 A
peak
Pulse CP150
500 A; 2 MHz Current Probe – AC/DC; 500 A
rms
; 700 A
peak
Pulse CP500
1,400 V, 100 MHz High-Voltage Differential Probe ADP305
1,400 V, 20 MHz High-Voltage Differential Probe ADP300
1 Ch, 100 MHz Differential Amplifier DA1855A
with Precision Voltage Source
* A wide variety of other passive, active, and differential probes are also available.
Consult LeCroy for more information.
Customer service
LeCroy oscilloscopes and probes are designed, built, and tested to ensure high
reliability. In the unlikely event you experience difficulties, our digital oscilloscopes
are fully warranted for three years, and our probes are warranted for one year.
This warranty includes: No charge for return shipping
• Long-term 7-year support
• Upgrade to latest software at no charge
