Real-time modulation FIR filter:

Nyquist, root-Nyquist, WCDMA, EDGE, Gaussian, rectangular, APCO

25 C4FM, IS-95, User FIR

(Applies real-time FIR filtering when playing waveforms with OSR=1. Helps reduce waveform

size for long simulation times. Option 660 not required).

Real-time baseband generator (Option 660)

Real-time baseband generator required

for real-time Signal Studio

applications

Cellular real-time applications

LTE-FDD, LTE-TDD, HSPA+/W-CDMA, GSM/

EDGE, cdma2000

Real-time navigation

GPS, GLONASS, Galileo

Real-time video applications

DVB-T/T2/H/S/S2/C/J.83 Annex A/C, ISDB-T/

Note: Option 660 is not required for real-time custom modulation (Option 431)
Memory: Shares memory with Options 653 and 655
Triggering: Same as Options 653 and 655
Markers: 3 markers available, all other features are same as Options 653 and 655

Digital baseband inputs/outputs (Option 003/004)

Options 003 and 004 activate the rear panel digital I/Q bus and enables connectivity to the N5102A digital signal interface module. In output

mode (003), you can deliver realistic complex-modulated signals such as LTE, GPS, WLAN, custom pulses and many others directly to your

digital devices and subsystems. In the input mode (004), the interface module ports your digital input to the signal generator's baseband

system, providing a quick and easy way of upconverting to calibrated analog I/Q, IF, or RF frequencies. In both operating modes, the interface

module adapts to your device with the logic type, data format, clock features, and signaling you require.
Data (requires N5102A)
Digital data format

User-selectable: 2's complement or binary offset, IQ (I, I-bar, Q, Q-bar) or digital IF output

(real, imaginary)

Data port

Dual 16-bit data buses support parallel, parallel IQ interleaved, parallel QI interleaved, or

serial port configuration

N5102A connectors (breakout boards) 144-pin Tyco Z-Dok+ connects to break-out boards (included with N5102A) that interface

with the following connector types: 68-pin SCSI, 38-pin dual AMP Mictor, 100-pin dual

Samtec, 20-pin dual 0.1 inch headers, 40-pin dual 0.1 inch headers

Logic types

Single-ended: LVTTL, 1.5V CMOS, 1.8V CMOS, 2.5V CMOS, 3.3.V CMOS
Differential: LVDS

Data output resampling

EXG baseband output is resampled to the arbitrary clock rate set by the user via real-time

curve-fit calculations.

1. See www.agilent.com/find/signalstudio for more information.
