Arbitrary waveform memory

Maximum playback

capacity

32 Msa (standard)
256 Msa (Option 021)
512 Msa (Option 022)

Maximum storage

capacity including

markers

3 GBytes/800 Msa (standard)
30 GBytes/7.5 Gsa (Option 009)
8 GBytes / 2 Gsa (Option 006)

Waveform segments

Segment length

60 samples to 32 Msa (standard)
60 samples to 256 Msa (Option 021)
60 samples to 512 Msa (Option 022)

Minimum memory

allocation per

segment

256 samples

Maximum number of

segments

8192

Waveform sequences

Maximum number of

sequences

> 2000 depending on non-volatile memory usage

Maximum number of

segments/sequence

32,000 (standard)
4 million (Option 021 or 022)

Maximum number of

repetitions

65,535

Triggers

Types

Continuous, single, gated, segment advance

Source

Trigger key, external, bus (GPIB, LAN, USB)

Modes

Continuous

Free run, trigger and run, reset and run

Single

No retrigger, buffered trigger, restart on trigger

Gated

Negative polarity or positive polarity

Segment advance

Single or continuous

External coarse delay time

5 ns to 40 s

External coarse delay resolution

5 ns

Trigger latency (Single trigger only)

356 ns + 1 sample clock period, nominal

Trigger accuracy (Single trigger only)

± 2.5 ns, nominal

Single trigger - restart on trigger mode will initiate a FIFO clear. Therefore, the latency

includes re-filling the buffer. The latency is 8 µs + (1406 x sample period) ± 1 sample clock

period, nominal

Multi-baseband generator

synchronization mode

(multiple sources)

Fan out

1 master and up to 15 slaves

Trigger repeatability

< 1 ns, nominal

Trigger accuracy

Same as normal mode

Trigger latency

Same as normal mode

Fine trigger delay range

See Internal IQ Baseband section

Fine trigger delay resolution

See Internal IQ Baseband section

IQ phase adjustment range

See Internal IQ Baseband section

Markers

Markers are defined in a segment during the waveform generation process, or from the front

panel; a marker can also be routed to the RF blanking, ALC hold functions, and alternate

amplitude; see Users Guide for more information
Marker polarity

Negative, positive

Number of markers

4

RF blanking/burst on/off ratio

> 80 dB

Alternate amplitude control switching speed

See amplitude section
