Loading Test
At 2,000 rpm:
Av.Volts: 13.3V
>13.5V: Max. 13.8V
>12.5V: Min. 12.8V
Press [Enter] for
results.
Follow the instructions, switch ON all electrical loads (Head Lights, Radio,
Air-condition, Heater, etc). Rev the engine up to 2,000 ~ 2,500 RPM by
referring to the dashboard meter, then press key and maintain the
engine speed for about 10 seconds and release the pedal. The maximum
and minimum voltages values will be captured. (Fig.65)
With the captured readings, analysis can done by referring to the limits as
indicated that MAX voltage should exceed 13.5V (max. voltage at 2,000
RPM) and MIN voltage should be more than 12.5V (min voltage during
idling speed).
Figure 64
Figure 65
Average
Charging volts.
Normal Charging
range limit. Captured Volts
readings
Loading Test
Switch ON all
electrical loads.
Rev engine up to
2,000 rpm. Press
[Enter].Hold on to
this 2,000 rpm for
10 seconds and
release the pedal.
