7. If the voltage drop is too great during the cranking, the tested results will
display as follows (Figure 52) and will prompt you to check the starter system.
8. During cranking when it detects that there is no drop in voltage, it will
display the following screen (Figure 53).
9.
Pressing the key at any moment will exit and return back to the main
menu screen. (Fig.49)
Figure 51
Figure 52
Figure 53
Result: OK
Min. Volts: 10.56V
Volt Drop: Normal
Press [Exit] to main
menu.
Result: High Drop
Min. Volts: 8.56V
Volt Drop: High
Check starter relay,
battery terminals or
battery has aged.
Press [Exit] to main
menu.
Result: Not detected
No change in volt
drop. Check clamping
at battery side and
test again.
Press [Exit] to main
menu.
