5. Press key will proceed to the display as follows: (Fig. 39)
6. Now transfer the BLACK tester clip from the battery [-] terminal to a
suitable position on the engine or chassis body leaving the RED clip still
attached to the battery [+] terminal.
7. Press key again to start analyzing (Fig. 40)
8. Once it has finished analyzing, it will prompt you with an instruction
(Fig. 41) stating that you have should unclamp the Black tester clip from
the engine or chassis body and transfer to the battery negative [-] terminal
within 20 seconds time limit if not the testing procedure has to be repeated
again as the gathered data will be lost.
Figure 39
Figure 40
Grounding Test
Clip the Black clip
to engine body or
the car chassis and
the Red clip to the
battery [+] post.
Press [Enter] to
begin.
Analysing ...
Please wait!
