7. Press key will show the results of the test (Figure 61):
8. If either minimum or maximum charging volts are not within the voltage
range limits then it will display one of the screen as below (Figures 62 &
63) and it will prompt you to check the charging system for the fault.
Testing with load at 2,000 RPM
As more electrical accessories, such as lights, heater, air condition, car
stereos, etc. were used; the electro-motive force decreases and this will allow
more amperage from the alternator to flow into the battery to compensate for
the added load. This test is to check the alternator’s behavior during loading.
9. Continue from the previous test (either Fig. 61, 62 or 63); proceed to the
next step by pressing key will enter to the display as follows. (Fig.64)
Figure 61
Figure 62 Figure 63
Results: Good
At 3,000 rpm,
No load Test:
Average Charging
Volts: 14.2V
Press [Enter] to
continue to Loading
Test.
Results: Low charge
At 3,000 rpm,
No load Test:
>13.3V: Min 13.2V
Check for loose
belt and the
alternator.
Results:High charge
At 3,000 rpm,
No load Test:
<15.0V: Max.15.6V
Check alternator
and the regulator.
