94
English
The network camera functions using a 16:9 image sensor. If you select a 16:9 resolution under
ROI, the live image displayed by the camera will be distorted by recording software or a recorder
system, or may not be displayed at all. To solve the problem, you must set a 4:3 resolution in the
network camera or ROI: 320x240, 640x480, 800x600 or 1024x768. This may involve cropping the
periphery of the live image.
10.5 Basic setting:
Video options
The network camera has four video streams with different quality settings available for flexible application.
Settings for streams 1, 2, 3 and 4
You can configure streams 1 – 4 in the respective menus.
“Image compression” Select from H.264/MPEG-4/MJPEG.
“Image size” Select your desired resolution here.
“Max. image rate” Select your maximum refresh rate here.
“Key frame interval
” Determines how often an Intra Frame is generated. The shorter the interval, the better
the image quality, and the higher the network usage costs.
“Video quality fixed image rate” Sets the image rate at a constant value. The image quality is reduced the
more complex an image is (e.g. motion).
“Fixed image quality” Sets the image quality at a constant value. The bit rate increases with the image
complexity (e.g. motion).
