317
trigger boot, di,
motion,
seq,
visignal
6/6 Indicate the trigger condition.
“boot” indicates system boot. “di”
indicates digital input.
“motion” indicates video motion detection. “seq”
indicates periodic condition.
“visignal” indicates video input signal loss
di 6/6 Indicate which di detected.
This field is required when trigger condition is “di”. One bit
represents one digital input. The LSB indicates DI 0.
mdwin 6/6 Indicate which motion detection windows
detected.
This field is required when trigger condition is
“md”.
One bit represents one window. The
LSB indicates the 1 st window.
For example, to detect the 1 st and 3 rd windows,
set mdwin as 5.
inter 1~999 6/6 Interval of period snapshot in minute.
This field is used when trigger condition is “seq”.
weekday 6/6 Indicate which weekday is scheduled. One
bit represents one weekday.
The bit0 (LSB) indicates Saturday. The
bit1 indicates Friday.
The bit2 indicates Thursday. The
bit3 indicates Wednesday. The bit4
indicates Tuesday. The bit5
indicates Monday.
The bit6 indicates Sunday.
For example, to detect events on Friday and
Sunday, set weekday as 66.
begintime hh:mm 6/6 Begin time of weekly schedule.
endtime hh:mm 6/6 End time of weekly schedule.
(00:00 ~ 24:00 means always.)
lowlightcondition 0, 1 6/6 Turn on IR led in some condition:
0: all conditions
1: low light condition
