ABUS TVIP41550 PIR network camera User Manual
Page 74
74
English
5. User functions
Open the main menu on the video server. The interface is divided into the following main areas:
Live image
Here you can view the live video image of the network camera
PIR network camera control
Video Stream
Select from video streams 1 – 4 to view the live image.
Snapshot
Create a snapshot (without ActiveX plug-in).
Virtual output 1 / 2
Switch the virtual output 1 / 2 on and off manually.
Configuration
Configure the video server (administrator settings).
Client Settings
Configure the client settings; you can find detailed information on the following pages.
Language
Set the interface language.
Control
Audio / video control
Live image
