107
English
13.2.4 Action
Here, you can configure the action that is to be executed if an alarm has been triggered.
“Trigger digital output for” When this option is enabled, the relay output for the video server is activated.
“Move to preset location” A preset location is activated when the alarm is triggered.
“Server” the selected medium is sent on a particular server (e.g. an email is sent with a snapshot).
“Create folders automatically” Folders are automatically created in the directory of the network drives
“Customized folder” The unique name of the folder is determined using variables.
The variables that are available can be found in the table below.
Symbol Example/function
/ Create a new folder
%IP = IP address 192.168.0.1
%N = Event name Motion_W1
%Y = Year 2010
%M = Month 03
%D = Day 04
%H = Hour 14
“Example text” “Example text”
Example:
The following entry would generate this path.
14. Recording
The recording section allows you to set up recordings with the option of setting up permanent video
recordings for SD cards or network shares. You can save up to 2 video settings in the video server.
Click “Add”
to create a new recording.
