7. Tilslutninger
BEMÆRK:
Inden du foretager ledningsføringen, skal du kontrollere, at
spændingsforsyningen er koblet fra!
7.1 Generelt
Tilslutning Beskrivelse
TRIG A
Hvis denne indgang aktiveres, begynder apparatet at
sende meddelelsen A.
TRIG B
Hvis denne indgang aktiveres, begynder apparatet at
sende meddelelsen B.
TRIG C
Hvis denne indgang aktiveres, begynder apparatet at
sende meddelelsen C.
ABORT / D
Hvis denne indgang aktiveres, begynder apparatet at
sende meddelelsen D.
Denne indgang kan dog også anvendes til af afbryde
opkaldsprocedurer (se 10.8 Afbrydelsesfunktion).
TAMP
Begge disse tilslutningsklemmer kan forbindes med
en alarmcentrals sabotagezone. Hvis apparatets hus
åbnes, afbrydes sabotagesløjfen til alarmcentralen, og
sabotagealarmen udløses.
0 V
0 V DC spændingsforsyning til alarmcentralen eller til
den eksterne netdel.
+12 V
+12 V DC spændingsforsyning til alarmcentralen eller
til den eksterne netdel.
O/P1 Programmerbar
transistorudgang. Negativt koblende
mod stel (0 V).
