SW Switchers • Reference Information

SW Switchers • Reference Information

Reference Information, cont’d

MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor

Specifications are subject to change without notice.

(7.31-010302-D1)

A-9

Control/remote — switcher

Serial control port ........................ RS-232, 9-pin D female connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations .... TX = 2, RX = 3, GND = 5
Contact closure ............................ 25-pin D female connector
Extron remote key pad control .. Extron KP 10 keypad .............. connects to

the 25-pin D female connector

IR controller module ................... Extron IR 101 ........................... connects to

the RS-232 9-pin D female connector

Program control ........................... Extron’s control program for Windows®

Extron’s Simple Instruction Set™ – SIS™

General

Power ............................................. 100VAC to 240VAC, 50/60 Hz, 10 watts,

internal, auto-switchable

Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /

10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing

Rack mount ................................... Yes, with optional front panel #60-141-01,

or universal rack shelf #60-032-01

Enclosure type .............................. Metal
Enclosure dimensions ................. 3.5" H x 8.5" W x 6.3" D

(2U high, half rack width)
8.9 cm H x 21.6 cm W x 16.0 cm D
(Depth excludes connectors.)

Product weight ............................. 4.0 lbs (1.8 kg)
Shipping weight ........................... 6 lbs (2.7 kg)
Vibration ....................................... ISTA/NSTA 1A in carton

(International Safe Transit Association)

Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, CSA
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Extron part number ..................... 60-309-01

Specifications are subject to change without notice.

(7.31-010202-D1)

A-8

SW 6 Component Specifications

Video

Gain ............................................... Unity
Bandwidth .................................... 180 MHz (-3dB), fully loaded
Crosstalk ....................................... -70dB @ 10 MHz

Video input

Number/signal type ................... 6 analog RGsB, component (R-Y, B-Y, Y),

S-video, NTSC/PAL/SECAM composite
video

Connectors .................................... 6 x 3 BNC female
Minimum/maximum levels ...... Analog ....... -5.0V to +5.0V p-p with no

offset

Impedance .................................... 75 ohms
Horizontal frequency .................. 15 kHz to 145 kHz
Vertical frequency ....................... 30 Hz to 170 Hz
Return loss .................................... -30dB @ 10 MHz

Video output

Number/signal type ................... 1 analog RGsB, component (R-Y, B-Y, Y),

S-video, NTSC/PAL/SECAM composite
video

Connectors .................................... 3 BNC female
Minimum/maximum levels ...... Analog ....... -5.0V to +5.0V p-p
Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz
DC offset ....................................... ±5mV maximum with input at 0 offset

Sync

Input type ..................................... 6 analog RGsB, component (R-Y, B-Y, Y)
Output type .................................. 1 analog RGsB, component (R-Y, B-Y, Y)
Standards ...................................... NTSC, PAL, SECAM
Input level ..................................... 0.5V to 5V p-p
Output level .................................. Same as input
Input impedance .......................... 510 ohms
Output impedance ...................... 75 ohms
