SW Switchers • Reference Information SW Switchers • Reference Information
Reference Information, cont’d
Input impedance .......................... 510 ohms
Output impedance ...................... 75 ohms
Max. propagation delay .............. 40 nS
Max. rise/fall time ....................... 4 nS
Polarity .......................................... Positive or negative
Control/remote — switcher
Serial control port ........................ RS-232, 9-pin D female connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations ... 2 = TX, 3 = RX, 5 = GND
Contact closure ............................ 25-pin female D connector
Extron remote key pad control .. Extron KP 10 keypad .............. connects to
the 25-pin D female connector
IR controller module ................... Extron IR 10 1 ........................... connects to
the RS-232 9-pin D female connector
Loop signal ................................... Momentary low, 1 mS min., 5 mS max.
Program control ........................... Extron’s control program for Windows®
Extron’s Simple Instruction Set ™ – SIS ™
General
Power ............................................. 100VAC to 240VAC, 50/60 Hz, 10 watts,
internal, auto-switchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
Rack mount ................................... Yes, with optional 3U front panel #60-141-
02 or 2U universal rack shelf #60-032-01
Enclosure type .............................. Metal
Enclosure dimensions ................. 4.3" H x 8.5" W x 6.25" D (3U high, 1/2
rack width)
10.9 cm x 21.6 cm x 15.9 cm
(Depth excludes connectors.)
Product weight
SW 4 AR MX HV ............. 4.6 lbs (2.1 kg)
SW 6 AR MX HV ............. 5.0 lbs (2.3 kg)
Shipping weight
SW 4 AR MX HV ............. 7 lbs (3.2 kg)
SW 6 AR MX HV ............. 8 lbs (3.6 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, CSA
SW 4/6 AR MX HV Specifications
Video
Gain ............................................... Unity
Bandwidth .................................... 600 MHz (-3dB), fully loaded
Crosstalk ....................................... -70dB @ 10 MHz
Switching speed ........................... 5 mS (max.)
Video input
Number/signal type ................... 4 or 6 (depending on the model) analog
VGA-UXGA RGBHV, RGBS, RGsB,
RsGsBs, component video,
S-video or NTSC/PAL/SECAM
composite video
Connectors .................................... 4 or 6 x 5 BNC female (depending on the
model)
Minimum/maximum levels ...... Analog ....... -5.0V to +5.0V p-p with no
offset
Impedance .................................... 75 ohms
Horizontal frequency .................. 15 kHz to 145 kHz
Vertical frequency ....................... 30 Hz to 170 Hz
Return loss .................................... -30dB @ 10 MHz
Video output
Number/signal type ................... 1 analog VGA-UXGA RGBHV, RGBS,
RGsB, RsGsBs, component video, S-video
or NTSC/PAL/SECAM composite video
(same as input)
Connectors .................................... 5 BNC female
Minimum/maximum levels ...... Analog ....... -5.0V to +5.0V p-p
Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz
DC offset ....................................... ±5mV maximum with input at 0 offset
Sync
Input type ..................................... 4 or 6 analog RGBHV, RGBS, RGsB,
RsGsBs
Output type .................................. 1 analog RGBHV, RGBS, RGsB, RsGsBs
(same as input)
Standards ...................................... NTSC, PAL, SECAM
Input level ..................................... 0.5V to 5V p-p
Output level .................................. Same as input
A-7 A-6
