SW Switchers • Reference Information SW Switchers • Reference Information
Reference Information, cont’d
A-5
Max. rise/fall time ....................... 4 nS
Polarity .......................................... Positive or negative
Control/remote — switcher
Serial control port ........................ RS-232, 9-pin D female connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations .... 2 = TX, 3 = RX, 5 = GND
Contact closure ............................ 25-pin D female connector
Extron remote key pad control .. Extron KP 10 keypad .............. connects to
the 25-pin D female connector
IR controller module ................... Extron IR 101 ........................... connects to
the RS-232 9-pin D female connector
Program control ........................... Extron’s control program for Windows®
Extron’s Simple Instruction Set ™ – SIS ™
General
Power ............................................. 100VAC to 240VAC, 50/60 Hz, 10 watts,
internal, auto-switchable
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
Rack mount ................................... Yes, with optional 2U front panel #60-141-
01 or 2U universal rack shelf #60-032-01
Enclosure type .............................. Metal
Enclosure dimensions ................. 3.4" H x 8.5" W x 6.25" D (2U high, 1/2
rack width)
8.5 cm H x 21.6 cm Wx 15.9 cm D
(Depth excludes connectors.)
Product weight
SW 2 AR MX ..................... 3.7 lbs (1.7 kg)
SW 4 AR MX ..................... 3.9 lbs (1.8 kg)
SW 6 AR MX ..................... 4.4 lbs (2.0 kg)
Shipping weight ........................... 6 lbs (2.7 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Safe Transit Association)
Listings .......................................... UL, CUL
Certifications ................................ CE, CSA
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
(7.31-103101-D1)
A-4
SW AR MX Specifications
Video
Gain ............................................... Unity
Bandwidth .................................... 600 MHz (-3dB), fully loaded
Crosstalk ....................................... -70dB @ 10 MHz
Switching speed ........................... 5 mS (max.)
Video input
Number/signal type ................... 2, 4, or 6 analog VGA-UXGA RGBS, RGsB,
RsGsBs, component video, S-video or
NTSC/PAL/SECAM composite video
Connectors .................................... 2, 4, or 6 x 4 BNC female
Minimum/maximum levels ...... Analog ....... -5.0V to +5.0V p-p with no
offset
Impedance .................................... 75 ohms
Horizontal frequency .................. 15 kHz to 145 kHz
Vertical frequency ....................... 30 Hz to 170 Hz
Return loss .................................... -30dB @ 10 MHz
External sync (genlock) ............... SW 4 and 6 AR MX only ........ 0.3V to 0.4V
p-p
Video output
Number/signal type ................... 1 analog VGA-UXGA RGBS, RGsB,
RsGsBs, component video, S-video or
NTSC/PAL/SECAM composite video
Connectors .................................... 4 BNC female
Minimum/maximum levels ...... Analog ....... -5.0V to +5.0V p-p
Impedance .................................... 75 ohms
Return loss .................................... -30dB @ 5 MHz
DC offset ....................................... ±5mV maximum
Sync
Input type ..................................... 2, 4, or 6 analog RGBS, RGsB, RsGsBs
Output type .................................. 1 analog RGBS, RGsB, RsGsBs
Standards ...................................... NTSC, PAL, SECAM
Input level ..................................... 0.5V to 5V p-p
Output level .................................. Same as input
Input impedance .......................... 510 ohms
Output impedance ...................... 75 ohms
Max. propagation delay .............. 40 nS
