SW MTP T Series Switchers • Reference Information SW MTP T Series Switchers • Reference Information
Reference Information, cont’d
Part Numbers
Switchers
Switcher Models Part number
SW2 MTP T 15HD A 60-648-01
SW4 MTP T 15HD A 60-649-01
SW6 MTP T 15HD A 60-650-01
Included Parts
Included Parts
External power supply 28-071-01
Tweeker
Universal Switcher Control Program
SW MTP T Series Switcher User’s Manual
Accessories
Accessories Part number
19" 1U Universal Rack Shelf 60-190-01
19" 1U Basic Rack Shelf 60-604-01
VersaTools universal rack shelf 60-190-20
VersaTools basic rack shelf 60-604-20
VersaTools back of the rack mounting kit 70-367-01
VersaTools furniture mounting kit 70-212-01
Mac HV/VGA adapter 26-340-02
SY-VGA/XGA 26-173-01
KP 6 remote control 60-111-20
IR 102 remote control kit 70-224-01
Cables
Male-to-female VGA audio cables Part number
VGA 3’ HRA 26-491-01
VGA 6’ HRA 26-491-02
A-5 A-4
Program control ........................... Extron’s control/configuration program
for Windows ®
Extron’s Simple Instruction Set (SIS ™ )
General
Power ............................................. Supplied by an external power supply
The SW MTP Series transmitters cannot supply remote power
to or receive remote power from attached receivers.
External power supply ............... 100 VAC to 240 VAC, 50/60 Hz, external,
autoswitchable; to 12 VDC, 1 A, regulated
Power input requirements ......... 12 VDC, 0.5 A
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, noncondensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, noncondensing
Rack mount ................................... Yes, with optional 1U rack shelf,
part #60-190-01 or 60-604-01; or
VersaTools
® rack shelf,
part #60-190-20 or 60-604-20
Also furniture mountable with optional
Under-Desk Mounting Kit #70-212-01
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.75" H x 8.75" W x 3.0" D
(1U high, half rack wide)
4.4 cm H x 22.2 cm W x 7.6 cm D
(Depth excludes connectors and toggle
switch.)
Product weight ............................. 0.8 lbs (0.4 kg)
Shipping weight .......................... 3 lbs (2 kg)
Vibration ....................................... ISTA 1A in carton
(International Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
