IPL Pro Series • Index

32

I

IP address

resetting to default (Reset All IP
Settings mode) 17

IR and RS-232 device control 5
IR drivers

IR driver file type (.eir files) 27

IR learning

distances and angles 9
frequencies accepted by the
controller 9
receiver/sensor location
and use 9

IR signal sensor (IR learning receiver)

location, use, reception angle 9

L

LAN (IP) ports

cabling, LEDs, and default
settings 14
default settings 14
used for power over Ethernet
(PoE) 12

licensing

for third-party software 28
Global Configurator
Professional 5
LinkLicense, use with third party
devices 2

LinkLicense

using with a third party device 2

M

MAC address

description 14
location on panel 11

modes

reset modes and procedures 15

mounting

UL rack mounting guidelines 10

P

password

default 14

port mapping

resetting to default 17

power connectors

troubleshooting 23
wiring, polarity, requirements

input power, external power
supply 12

R

rack mounting

UL rack mounting guidelines 10

Reset button

Reset button and LED location 9
using to reset the unit 15

resetting the unit

manual reset modes 15

RS-232, RS-422, RS-485 default
protocol and COM port pin
configurations 13

S

serial communication protocol

COM port defaults 13

serial ports

wiring COM ports 13

straight-through cable (wiring and
when to use) 14
subnet

default value 14
definition of subnet mask 26
resetting to default 17

system requirements 5

T

third-party software

list of software licenses 28

TouchLink Pro touchpanel

as part of a system with a
controller 2

touchpanel

as part of a system with a
controller 2

troubleshooting 23

data connections 23
device control connections and
configuration 23
power connections 23

U

Underwriters Laboratories (UL)

UL rack mounting guidelines 10

updating the firmware 30
username

default 14
