IPL Pro Series • Introduction 4
Application Diagrams
The following figures shows examples of types of devices that can be connected to some of
the ports on the IPL Pro Series control processors.
POWER
12V
0.2A MAX
G Tx Rx RTS CTS
COM
IPL PRO S1
LAN / PoE
MAC: 00-05-A6-XX-XX-XX S/N: ####### E######
Extron Extron
MODEL 80
FLAT PANEL
1
TCP/IP
Network
Media Player
RS-232 Ethernet/PoE
Ethernet/PoE
Ethernet
HDMI with
Embedded Audio
Flat Panel Display
Extron
IPL Pro S1
IP Link Pro Control Processor
Extron
TLP Pro 520M
5" Wall Mount
TouchLink Pro
Touchpanel
Figure 2. An IPL Pro S1 Application
1 2 3 4 5 6 7 8 9 10 11
MEDIA I
CONTROL
MEDIA II
12 13 14 15
WARNING
SEE USER GUIDE BEFORE USING THIS EQUIPMENT DO NOT REMOVE THIS PANEL NO USER-SERVICEABLE PARTS INSIDE REFER ALL SERVICING TO QUALIFIED SERVICE PERSONNEL THIS EQUIPMENT MUST BE GROUNDED/EARTHED DO NOT OBSTRUCT VENTILATION GRILLES DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
ATTENTION OBSERVE PRECAUTIONS FOR HANDLING
ELECTROSTATIC SENSITIVE
DEVICES
OUT
HDC
P
C OMP
L IA N T
OUT
HDC
P
C OMP
L IA N T
IN
HDC
P
C OMP
L IA N T
IN
HDC
P
C OMP
L IA N T
IN IN IN
POWER
12V X.XA MAX
G Tx Rx RTS CTS
COM 1
G Tx Rx RTS CTS
COM 3
G Tx Rx RTS CTS
COM 2
G Tx Rx RTS CTS
COM 4
G Tx Rx RTS CTS
COM 6
G Tx Rx RTS CTS
COM 5
LAN / PoE
IPL PRO S6 MAC: 00-05-A6-XX-XX-XX S/N: ####### E######
STANDBY/ON PQLS HDMI OPEN/CLOSE FL OFF USB
CCTV
Cameras
Extron
Quantum Elite
Scalable Multi-Graphic
Videowall Processor System
Quantum
Elite
Control
Software
RS-232
RS-232
RS-232
DVI
RGB
DVI
RGB
Blu-ray Player
PC
PC
PC
PC
Control
VLAN
HDCP-Compliant Displays
DSS Receiver
DSS Receiver
DSS Receiver
Composite or S-video
HDMI
HDMI
HDMI
HDMI
HDMI HDMI
Extron
TLP Pro 1520TG
15" Tabletop
TouchLink
Pro Touchpanel
Extron
IPL Pro S6
IP Link Pro Control Processor
Ethernet
Ethernet/
Power
Ethernet/
Power
Ethernet/PoE
Power
Injector
Figure 3. An IPL Pro S6 Application
Will need to add an
example of a CR88
or IRS8 for rev. B.
