IPL Pro Series • Hardware Features and Installation

17

IPL Pro Series Control Processor Reset Mode Summary

Mode

Activation

Result

Purpose and Notes

Reset All IP Settings

To reset all IP settings:

1.

Hold down the Reset button for about 6 seconds until

the Power LED blinks twice (once at 3 seconds, again at

6 seconds).

2.

Release and press Reset momentarily (for <1 second) within

1 second*.
* Nothing happens if the momentary press does not occur within

1 second.

Reset All IP Settings mode:

Sets the IP address back to factory default

(192.168.254.250)

Sets the subnet back to factory default

(255.255.255.0)

Sets the default gateway address to the

factory default (0.0.0.0)

Sets all other IP settings, addresses, and

domain and host names back to factory

default

Sets port mapping back to factory default

Turns DHCP off

Turns events off

Stops all user-created programs.

Reset All IP Settings

mode enables you to

reset IP settings and port

maps to factory defaults.

Reset to Factory Defaults

To reset the unit to all factory default settings:

1.

Hold down the Reset button for about 9 seconds until the

Power LED blinks three times (once at 3 seconds, again at

6 seconds, again at 9 seconds).

2.

Release and press Reset momentarily (for <1 second) within

1 second*.
* Nothing happens if the momentary press does not occur within

1 second.

Reset to Factory Defaults mode performs a
complete reset to factory defaults (except
the firmware).

Does everything Reset All IP Settings mode

does

Clears driver-port associations (serial,

Ethernet) and port configurations

Removes button/touchpanel configurations

Resets all IP options

Removes schedules, settings, macros

Removes/clears all user-loaded files and

configurations from the control processor

Reset to Factory
Defaults mode is useful
if you want to start over
with configuration and
uploading.

IR,
