Extender Plus Series • Installation and Operation 2
Installation and
Operation
This section covers the following topics:
• UL Guidelines
• Installation Instructions
• Front Panel Features and Cabling
• Rear Panel Features and Cabling
• EDID Minder Operation
• Pre-Installation Testing and Troubleshooting
• Mounting
• Application Diagrams
ATTENTION: Potential damage to property. Installation and service must be
performed by authorized personnel only (see “Installation Instructions,” below). Use a
UL-approved electrical box (see “UL Guidelines,” below).
UL Guidelines
1. The Extender must be installed in an Underwriters Laboratories (UL) listed junction box.
The UL-approved electrical wall box (junction box) is not included with the unit; the
installer is responsible for obtaining and installing the box.
2. The unit must be installed in accordance with the National Electrical Code and with local
electrical codes.
Installation Instructions
Depending on the model, the Extenders can be mounted into furniture, a wall, an
Ackermann floorbox, or an Extron HSA 400 Series or HSA 800 Series enclosure.
Preparing the Site and Installing the Wall Box
Considerations
Choose a location that allows cable runs without interference. Allow enough depth for both
the wall box and the cables. You may need to install the cables into the wall, furniture, or
conduits before installing the line driver.
• The Extender Plus AAP can be installed in an Extron two-gang, four-gang, or half rack
width AAP Architectural Adapter Plate or in the faceplate of another Extron device that
accepts double-space AAPs, such as an interface or distribution amplifier. See the
mounting instructions for the adapter plate or device.
• The Extender Plus D can be installed in a standard or compact one-gang wall box
The installation must conform to national and local electrical codes and to the size
requirements of the Extender. See the Extender Plus D “
Dimensions ” on page 15 and
“ Template ” on page 16.
