Matrix 3200/6400 Series Switchers • FPC 1000 • User’s Manual • Extron ii
Contents
Figure 3-15. Misc/System Reset menu (shown with Factory Default selected) ......................... 3-16
Figure 3-16. Terminal Mode display of RS-232 dialog – example of a Tie command. ................ 3-17
Figure 3-17. Status/Remote menu showing MKP/MCP 1000s and their status. ........................ 3-18
Figure 3-18. Error screen showing message, category and number ......................................... 3-19
The following icons may be used in this manual:
_________ Important information – for example, an action or a step that must be done
before proceeding.
_________ A Warning – possible dangerous voltage present.
_________ A Warning – possible damage could occur.
_______ A Note, a Hint, or a Tip that may be helpful.
________ Possible Electrostatic Discharge (ESD) damage could result from touching
electronic components.
________ Indicates word definitions. Additional information may be referenced in another
section, or in another document.
Extron’s Matrix 3200/6400 Series FPC 1000 User’s Manual
68-355-02
Rev A, 08-89
Rev. B, 07-99
Rev. C, 01-02
(add warning and MCP 1000)
Written and printed in the U.S.A.
FCC Class A Compliance
The user is cautioned that any changes or modifications not expressly
approved by Extron Electronics could void the user’s authority to
operate the equipment per FCC regulations.
Note: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his
own expense.
Note: This unit was tested with shielded cables on the peripheral
devices. Shielded cables must be used with the unit to ensure
compliance.
