DVC 501 SD • Remote Configuration and Control 23
Symbol Definitions
• = Space
] = Carriage return with line feed
} = Carriage return with no line feed
E = Escape
| = Pipe (vertical bar) character. Has the same function as ].
W = Has the same function as E .
X! = On or off; enable or disable 0 = Off or disable
1 = On or enable
X@ = Input standard — = Signal not supported
0 = No signal
1 = NTSC
2 = PAL
3 = 720p
4 = 1080i
5 = 1080p HD-SDI
6 = 1080p 3G SDI
X# = Internal temperature (in degrees
Celsius)
X$ = Test pattern 0 = Off (default)
1 = Color Bars
2 = Grayscale
3 = 4x4 Crosshatch
4 = Alternating Pixels
5 = Crop
6 = 1.33 Aspect Ratio Crop
7 = 1.78 Aspect Ratio Crop
8 = 1.85 Aspect Ratio Crop
9 = 2.35 Aspect Ratio Crop
X% = Output polarity 0 = H– V–
1 = H– V+
2 = H+ V–
3 = H+ V+ (default)
X^ = Output sync format 0 = RGBHV (default)
1 = RGBS
2 = RGsB
3 = YUV bi-level
4 = YUV tri-level
X& = SDI audio channels (AES 1 through 8
stereo pairs)
X* = Audio attenuation level 0 through -18 dB (-5dB = 5)
