13
DVCM 50 • Quick Start Guide
PRELIMINAR
Y
The installation process has two parts: installing the software and installing the IP
(IR) drivers. The fi les you will install need approximately 32 MB (megabytes) of
total of hard disk space.
To install the software and IR drivers onto the PC hard drive, follow these steps.
Step 1
Insert the CD ROM into your CD drive.
The disk should start automatically. If it
does not, run LAUNCH.EXE from the CD.
Step 2
Click Install Program
on the Software Installation screen.
Software Installation screen on the DVCM 50 CD
Step 3
Click Run on the File Download window
that appears, to begin installing the
program. A security prompt window opens.
File Download window
Step 4
Click Run on the security prompt window
to continue with the installation.
