DVCM 50 Quick Start Guide, cont’d
DVCM 50 • Quick Start Guide 8
PRELIMINAR
Y
PRELIMINAR
Y
1
2
3
4
E
1
2
3
4
E
1
2
3
4
E
1
2
3
4
E
LED Off
LED Blinking
LED On
Command 1 ready to
be learned Command 2 ready
to be learned
Command 1 learned Command 3 ready
to be learned.
Command 2 learned
Command 1 learned Command 4 ready
to be learned
Command 3 learned
Command 2 learned
Command 1 learned
Activation of learning indicator LEDs during button programming
Step 5
Within 5 seconds, point the DVD or VCR remote control at the IR learning
sensors on the rear panel, and press the remote control button whose function
you want the selected DVCM button to learn.
If the IR command is learned successfully, the IR learning indicator LEDs blink
in rapid progression from the top to the bottom, then back to the top.
If the IR code that you entered results in an error, the buttons blink randomly.
For repeating command codes, such as those that increment/decrement a
function (for example, scanning up and down through the channels on a VCR
that is in TV mode), hold the button on the DVD or VCR remote control for at
least 3 seconds.
Step 6
Do one of the following:
If you want to add another command to the same button, press the same
DVCM button again.
The next Learning LED on the rear panel begins
fl ashing. Repeat step 5 to add the desired command. (You can program up to
four commands on one button.)
If you want to program commands onto another DVCM button, repeat steps 3
through 5 for the next button that you want to program.
Step 7
When fi nished programming buttons, set confi guration switch #1 on the rear
panel to Off.
Verify that the commands you entered have been learned by pressing
the buttons that you programmed and observing the actions of the DVD/VCR.
It may be helpful to program all DVD functions fi rst, then the VCR functions.
Programming the DVD and VCR mode buttons
The procedure for programming commands onto the DVD and VCR buttons is
the same as the procedure for programming the other buttons (see the previous
section), except that you skip step 4. Pressing either of these buttons once
accomplishes the following:
Places the DVCM in button’s mode (DVD or VCR, depending on which button
was pressed).
Selects the button’s next available memory block for programming.
•
•
•
•
•
•
