MIQ/CR3; DIQ/CR3 Technical data
6 - 1 ba76032e01 01/2012
6 Technical data
Note
General technical data on MIQ modules are given in the T
ECHNICAL
DATA chapter of the IQ S ENSOR N ET system operating manual.
Electrical data
Instrument safety
Terminal connections
Nominal voltage Max. 24 VDC via the IQ S ENSOR N ET (for
details, see the T ECHNICAL DATA chapter of
the IQ S ENSOR N ET system operating
manual)
Power consumption 3 W
Protective class II
Overvoltage
category II
Applicable norms – EN 61010-1
– UL 3111-1
– CAN/CSA C22.2 No. 1010.1
IQ S ENSOR N ET
connections
2
Additional connectable SENSORNET
terminator (terminating resistor)
Number of relay
contacts 3
Number of current
outputs 3
Terminal type Screw-type terminal strip, accessible by
opening the lid
Terminal ranges Solid wires: 0.2 ... 4.0 mm
2
AWG 24 ... 12
Flexible wires: 0.2 ... 2.5 mm
2
Line cross-section of
cables carrying mains
voltage Europe: 1.5 ... 4.0 mm
2
USA: AWG 14 ... 12
Cable feeds 4 cable glands M16 x 1.5 on the underside
of the module
