6
3-13 N-14 Controls 26
3-14 IR Illuminator Operations 28
4-1 Shading 33
4-2 Edge Glow 33
4-3 Emission Points and Bright Spots 34
4-4 Fixed-Pattern Noise 34
4-5 Chicken Wire 34
4-6 Browpad Replacement 36
4-7 Chin Strap Reinstallation 36
4-8 Chin Cup Replacement 36
A-1 N-14 Spare Parts 38
B-1 Intensifier Tube Replacement 40
LIST OF TABLES
TABLE TITLE PAGE
2-1 N-14 System Description 12
2-2 Mechanical Data 12
2-3 Electrical Data 13
2-4 Optical Data 13
2-5 Environmental Data 14
2-6 N-14 Standard Components 14
2-7 N-14 Optional Equipment 15
3-1 N-14 Controls and Indicators 27
4-1 Preventive Maintenance Checks and Services 30
4-2 Operator Troubleshooting 32
A-1 N-14 List of Spare Parts 38
HOW TO USE THIS MANUAL
USAGE
You must familiarize yourself with the entire manual before operating the equipment. Before perform-
ing any kind of maintenance on your device, read the section on maintenance in its entirety. Follow all
WARNINGS, CAUTIONS, and NOTES.
MANUAL OVERVIEW
This manual contains sections on Operating and Maintaining the N-14 Night Vision Monocular.
The list of Spare Parts can be found in Appendix A.
The Intensifier Tube Replacement Manual can be found in Appendix B.
The Product Warranty Registration Card can be found in Appendix C.
