14
ITEM DATA
Built-in IR Illuminator
— Power
— Illumination Range
— Focus Distance
— Illumination Wavelength 50 mW
20 m
3 m
850 nm
* Optional.
TABLE 2-5. ENVIRONMENTAL DATA
ITEM DATA
Operating Temperature -40 to +50 °C
Storage Temperature -50 to +70 °C
Humidity 95 %, 25 °C to 40 °C for 48 hr
Illumination Required Natural night illumination
(overcast starlight to moonlight)
Immersion 20 m for 1 hr
MIL-STD-810 Complies
2.3 STANDARD COMPONENTS
The standard components of the N-14 are shown in Figure 2-2 and listed in Table 2-6.
The ITEM NO. column indicates the number used to identify items in Figure 2-2.
1
2
3
4
5
6 7
8
FIGURE 2-2. N-14 STANDARD COMPONENTS
TABLE 2-6. N-14 STANDARD COMPONENTS
ITEM NO. DESCRIPTION qUANTITY
1 Night Vision Monocular 1
2 Lens Cap 1
3 Eye-cup 1
4 Battery Adapter 1
5 Battery 123A Lithium 1
6 Operation and Maintenance Manual 1
7 Carrying Case 1
8 Neck Cord 1
TABLE 2-4. CONTINUED
