38
APPENDIx
A. N-14 LIST OF SPARE PARTS
The parts authorized in this list of spare parts are required for operator maintenance. This list includes
parts that must be removed in order to replace authorized parts.
ITEM NO. Column indicates the number used to identify items in Figure A-1.
PART NO. Column indicates the primary number used by the manufacturer to identify an item; this
number controls the design and characteristics of the item by means of its engineering, specifications,
standards, and inspection requirements.
TABLE A-1. N-14 LIST OF SPARE PARTS
ITEM NO. DESCRIPTION PART NO.
1. Battery Cap N14BC
2. CR123A Lithium Battery CR123A
ALT AA Alkaline Battery
3. Battery Adapter N14BA
4. Battery Cap Retainer N14BCR
5. Lens Cap N14LC
6. Objective Lens Assembly N14OLA
7. Eyepiece Assembly N14EPA
8. Eyecup Assembly N14ECA
9. Pivotal Focusing Lens N14PFL
10. Operation button N14FS
12
7
10
9
FIGURE A-1. N-14 SPARE PARTS
4
11
5
6
2 3
1
8
13
ALT
