SouthBridge Configuration SouthBridge Configuration SouthBridge Configuration SouthBridge Configuration SouthBridge Configuration
The SouthBridge Configuration menu allows you to change the Southbridge
related settings.
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.58 (C)Copyright 1985-2004, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
South Bridge Chipset Configuration
USB Functions [4 USB Ports]
USB 2.0 Controller [Disabled]
PCIE Ports Configuration
PCI Express Port 0 [Auto]
PCI Express Port 4 [Auto]
PCI Express Port 5 [Auto]
USB Function [4 USB Ports] USB Function [4 USB Ports] USB Function [4 USB Ports] USB Function [4 USB Ports] USB Function [4 USB Ports]
Allows you to enable a specific number of USB ports, or disable the USB
function. Configuration options: [Disabled] [2 USB Ports] [4 USB Ports]
USB 2.0 Controller [Disabled] USB 2.0 Controller [Disabled] USB 2.0 Controller [Disabled] USB 2.0 Controller [Disabled] USB 2.0 Controller [Disabled]
Allows you to enable or disable the USB 2.0 controller.
Configuration options: [Enabled] [Disabled]
PCIE Port Configuration PCIE Port Configuration PCIE Port Configuration PCIE Port Configuration PCIE Port Configuration
PCI Express Port 0 [Auto]
Allows you to set or disable the PCI Express Port 0.
Configuration options: [Auto] [Disabled]
PCI Express Port 4 [Auto]
Allows you to set or disable the PCI Express Port 4.
Configuration options: [Auto] [Disabled]
PCI Express Port 5 [Auto]
Allows you to set or disable the PCI Express Port 5.
Configuration options: [Auto] [Disabled]
Options
Disabled
2 USB Ports
4 USB Ports
