C h a p t e r 2 : H a r d w a r e s e t u p C h a p t e r 2 : H a r d w a r e s e t u p C h a p t e r 2 : H a r d w a r e s e t u p C h a p t e r 2 : H a r d w a r e s e t u p C h a p t e r 2 : H a r d w a r e s e t u p 2 - 1 2 2 - 1 2 2 - 1 2 2 - 1 2 2 - 1 2
2.5 Expansion slot
2.5.1 2.5.1 2.5.1 2.5.1 2.5.1 Installing an expansion card to the Installing an expansion card to the Installing an expansion card to the Installing an expansion card to the Installing an expansion card to the
riser card bracket
riser card bracket riser card bracket riser card bracket riser card bracket
The barebone server comes with a riser card bracket. You need to remove
the bracket if you want to install a PCI-X and/or a PCI Express x8 expansion
cards.
To install a PCI-X card:
2. Place the riser card bracket on a
flat and stable surface, then
remove the screw from the
PCI-X slot bay.
3. Install a PCI-X card to the
bracket as shown, then secure
the card with a screw.
1. Firmly hold the riser card
bracket, then pull it up to
detach it from the PCI Express
x8 and PCI-X slots on the
motherboard.
P C I - X s l o t P C I - X s l o t P C I - X s l o t P C I - X s l o t P C I - X s l o t
