ASUS MES-N User’s Manual 11
2.2 Motherboard Parts
2. FEATURES
2. FEA
TURES
Motherboard Parts
19
21
20
18 17 16 15
9
3 2 1 4 5 6 7 8
10
11
12
13
14
12
13
14
15
16
17
18
19
20
21
COM1 Connector ( B )
Parallel Connector ( T )
COM2 Connector ( B )
PS/2 Mouse ( T )/Keyboard ( B ) Connector
RJ-45 Connector
LAN LED
VGA Connector
Joystick/MIDI Connector
LCD Header (w/ LCD Chip onboard)
LCD Chip (optional)
Audio CODEC (optional)
1
2
3
4
5
6
7
8
9
10
11
LAN Controller Chip (optional)
Yamaha Audio Chip (on audio model only)
Slim CD-ROM Connector
Programmable Flash EEPROM
SiS South Bridge
with Integrated Hardware Monitoring
Multi-I/O Chip
CPU ZIF Socket 370
DIMM Sockets
SiS Chipset with Heatsink
Optional VGA Memory (up to 8MB)
T : Top
B : Bottom
