ASUS P5Q-EM DO 2-23
2.5.2 Chipset
The Chipset menu allows you to change the advanced chipset settings. Select an item then
press to display the sub-menu.
Advanced Chipset Settings
WARMING: Setting wrong values in below sections
may cause system to malfunction.
North Bridge Configuration
ME Subsystem Configuration
VE Subsystem Configuration
Configure North Bridge
features.
BIOS SETUP UTILITY
Advanced
North Bridge Chipset Configuration
Memory Remap Feature [Enabled]
Allows you to enable or disable the remapping of the overlapped PCI memory above
the total physical memory. Enable this option only when you install
64-bit operating system.
Configuration options: [Disabled] [Enabled]
Initiate Graphic Adapter [PEG/PCI]
Allows you to decide which graphics controller to use as the primary boot device.
Configuration options: [IGD] [PCI/IGD] [PCI/PEG] [PEG/IGD] [PEG/PCI]
IGD Graphics Mode Select [Enabled, XXMB]
Allows you to select the size of system memory used by the internal graphics device.
Configuration options: [Disabled] [Enabled, 32MB] [Enabled, 48MB] [Enabled, 64MB]
[Enabled, 128MB] [Enabled, 256MB]
GTT Graphics Memory Size [No VT mode, 2MB]
This item is not available.
PAVP Function [Disabled]
Allows you to set the GMCH Protected Audio Video Path (PAVP) BIOS support.
Configuration options: [Disabled] [Lite Mode] [Paranoid]
DVMT Memory [256MB]
Configuration options: [128MB] [256MB] [Maximum DVMT]
North Bridge Chipset Configuration
Memory Remap Feature [Enabled]
Initiate Graphic Adapter [PEG/PCI]
IGD Graphics Mode Select [Enabled, 32GB]
GTT Graphics Memory Size [No VT mode, 2MB]
PAVP Function [Diabled]
DVMT Memory [256MB]
BIOS SETUP UTILITY
Advanced
ENABLE: Allow
remapping of
overlapped PCI memory
above the total
physical memory.
DISABLE: Do not allow
remapping of memory.
