5-22 Chapter 5: BIOS setup
5.4.7 Onboard Devices Configuration
Select Screen
Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
v02.58 (C)Copyright 1985-2007, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Configure Win83627EHG-A Super IO Chipset
Serial Port1 Address [3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Serial Port2 Mode [Normal]
OnBoard LAN1 Boot ROM [Enabled]
OnBoard LAN2 Boot ROM [Enabled]
Allows BIOS to Select
Serial Port1 Base
Addresses.
Serial.Port1.Address.[3F8/IRQ4]
Allows BIOS to select serial port1 base address.
Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4]
Serial.Port2.Address.[3F8/IRQ4]
Allows BIOS to select serial port2 base address.
Configuration options: [Disabled] [2F8/IRQ3] [2E8/IRQ3]
Serial Port2 Mode [Normal]
Allows BIOS to select a mode for serial port2.
Configuration options: [Normal] [IrDA] [ASK IR]
The following two items appear when you set Serial.Port2.Mode to [IrDA] and
[ASK IR].
IR.I/O.Pin.Select.[SINB/SOUTB]
Allows BIOS to select the receiver or transmit pin for the serial port2.
IR.Duplex.Mode.[Half.Suplex]
Allows BIOS to select full or half Duplex for the serial port2.
OnBoard LAN1/2 Boot ROM [Enabled]
Enables or disables the LAN Boot ROM.
