Chapter 2: Hardware setup

2-2

2.1

Chassis cover

2.1.1.

Removing.the.cover

1. Use a Phillips screwdriver to remove the screw on each front end of the top

cover.

2. Loosen the two thunbscrews on the

rear panel to release the top cover

from the chassis.

3. Firmly hold the cover and slide it

toward the rear panel for about half

an inch until it is disengaged from

the chassis.

4. Lift the cover from the chassis.

1/2 inch distance
