GigaX Series L2 Managed Switch User’s Guide

4.5.9

Default Port VLAN and CoS

Some VLAN tag related field settings for each port are included in this page. It
includes:

Port: select the port to configure

PVID: port-based VLAN ID. Every untagged packet received from this
port will be tagged with this VLAN group ID

CoS (Class of Service) value: every untagged packet received from this
port will be assigned to this CoS in the VLAN tagged.

Click on

to change the content in the port list window. Click on

to save the configuration. To make the configuration effective, go to

“Save Configuration” page, then click

.

Figure 27. Default Port VLAN and CoS

52
