ASUS P8P67 WS Revolution 4-5
No. Function description
1 DIGI+ VRM Load-line Calibration
Higher load-line calibration could get higher voltage and good overclocking
performance but increase the CPU and VRM thermal.
2 DIGI+ VRM CPU Current Capability
DIGI+ VRM CPU Current Capability provides wider total power range for
overclocking. A higher value setting gets higher VRM power consumption delivery.
3 DIGI+ VRM Frequency
Switching frequency will affect the VRM transient response and component
thermal. Higher frequency gets quicker transient response.
4 DIGI+ VRM Phase Control
Increase phase number under heavy system loading to get more transient and
better thermal performance. Reduce phase number under light system loading to
increase VRM efficiency.
5 DIGI+ VRM Duty Control
DIGI+ VRM Duty Control adjusts the current of every VRM phase and the thermal
of every phase component.
• The actual performance boost may vary depending on your CPU
specification.
• Do not remove the thermal module. The thermal conditions should be
monitored.
Refer to the software manual in the support DVD or visit the ASUS website at
www.asus.com for detailed software configuration.
