3.6

Monitor menu

The Monitor menu displays the system temperature/power status, and allows you
to change the fan settings.

Main

Ai Tweaker

Advanced

Monitor

Boot

Tool

Exit

→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit

EFI BIOS Utility - Advanced Mode

CPU Temperature / MB Temperature [xxx�C/xxx�F]

[xxx�C/xxx�F]

The onboard hardware monitor automatically detects and displays the CPU
and motherboard temperatures. Select

Ignore if you do not wish to display the

detected temperatures.

CPU Fan Speed [xxxx RPM] or [Ignore] / [N/A]

Chassis Fan 1/2/3 Speed [xxxx RPM] or [Ignore] / [N/A]

Power Fan Speed [xxxx RPM] or [Ignore] / [N/A]

The onboard hardware monitor automatically detects and displays the CPU,
chassis, and power fan speed in rotations per minute (RPM). If the fan is not

and power fan speed in rotations per minute (RPM). If the fan is not

fan speed in rotations per minute (RPM). If the fan is not

connected to the motherboard, the field shows

N/A. Select Ignore if you do not

wish to display the detected speed.

Scroll down to display the following items:

CPU Temperature

+45ºC / +113ºF

MB Temperature

+34ºC / +93ºF

CPU Fan Speed

3325 RPM

Chassis Fan 1 Speed

N/A

Chassis Fan 2 Speed

N/A

Chassis Fan 3 Speed

N/A

Power Fan Speed

N/A

CPU Q-Fan Control

Enabled

CPU Fan Speed Low Limit

600 RPM

CPU Fan Profile

Standard

Chassis Q-Fan Control

Enabled

Chassis Fan Speed Low Limit

600 RPM

Chassis Fan Profile

Standard

CPU Voltage

+1.184 V

3.3V Voltage

+3.312 V

5V Voltage

+5.080 V

12V Voltage

+12.192 V

Anti Surge Support

Enabled
