3-2 Chapter 3: BIOS setup
3.2.1 EZ Mode
By default, the EZ Mode screen appears when you enter the BIOS setup program.
The EZ Mode provides you an overview of the basic system information, and
allows you to select the display language, system performance mode and boot
device priority. To access the Advanced Mode, click
Exit/Advanced Mode, then
select Advanced Mode.
The default screen for entering the BIOS setup program can be changed. Refer
to the
Setup Mode item in section section 3.7 Boot memu for details.
P8P67 WS REVOLUTION
BIOS Version : 0602 Build Date : 11/04/2010
CPU Type : Intel(R) Core(TM) i5-2300 CPU 0 @ 2.80GHz Speed : 2800 MHz
Total Memory : 1024 MB (DDR3 1066MHz)
Exit/Advanced Mode
Temperature Voltage Fan Speed
CPU +113.0ºF/+45.0ºC CPU 1.248V 5V 5.160V CPU_FAN 3325RPM PWR_FAN1 N/A
MB +75.2ºF/+40.0ºC 3.3V 3.344V 12V 12.248V CHA_FAN1 N/A CHA_FAN2 N/A
English
EFI BIOS Utility - EZ Mode
Monday [11/08/2010]
Normal
Quiet
Performance Energy Saving
System Performance
Boot Menu(F8) Default(F5)
Use the mouse to drag or keyboard to navigate to decide the boot priority.
Boot Priority
Exits the BIOS setup program without saving
the changes, saves the changes and resets
the system, or enters the Advanced Mode
Selects the display language
of the BIOS setup program
Displays the CPU/motherboard
temperature, CPU/5V/3.3V/12V voltage
output, CPU/chassis/power fan speed
Power Saving mode
Normal mode ASUS Optimal
mode
Loads optimized default Selects the boot device priority
Selects the boot
device priority
• The boot device options vary depending on the devices you installed to the
system.
• The Boot Menu(F8) button is available only when the boot device is
installed to the system.
Displays the system properties of
the selected mode on the right hand
side
Clicks to display all fan
speeds if available
