5-24 Chapter 5: BIOS setup
PCIE Slot Option Rom Configuration
E n a b l e s o r d i s a b l e s
Boot Option for Legacy
Mass Storage Device with
Option ROM.
Legacy 0pROM Support
Launch Storage OpROM [Enabled]
CPU1_PCIE1 Option Rom [Enabled]
CPU1_PCIE2 Option Rom [Enabled]
CPU1_PCIE3 Option Rom [Enabled]
CPU1_PCIE4 Option Rom [Enabled]
CPU2_PCIE1 Option Rom [Enabled]
CPU2_PCIE2 Option Rom [Enabled]
CPU2_PCIE3 Option Rom [Enabled]
CPU2_PCIE4 Option Rom [Enabled]
PCIE5 Option Rom [Enabled]
Launch Storage OpROM [Enabled]
Allows to enable or disable Boot Option for Legacy Mass Storage Devices with
Option ROM. Configuration options: [Disabled] [Enabled]
CPU1_PCIE1~4/CPU2_PCIE1~4 Option Rom [Enabled]
Allows you to enable or disable the CPU1/CPU2 PCIE1~4 Option Rom items.
Configuration options: [Disabled] [Enabled]
PCI5 Option Rom [Enabled]
Allows you to enable or disable the PCIE5 Option Rom.
Configuration options: [Disabled] [Enabled]
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
5.4.7 Intel TXT(LT-SX) Configuration
The Intel TXT(LT-SX) configuration automatically detects and displays the Intel
TXT(LT-SX) hardware support.
Intel TXT(LT-SX) Hardware Support
CPU: TXT Feature Supported
Chipset: TXT Feature Supported
Intel TXT(LT-SX) Configuration
TXT Support Disabled
Intel TXT(LT-SX) Dependencies
The following must be supported and enabled.
VT-d Support Enabled
VT Support Enabled
TPM Support Enabled
TPM State Disabled
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
