2-23 ASUS ESC4000 G2 Series
5. Carefully cut the cable tie on the
SATA/SAS cables and SGPIO
cables.
6. Connect the SGPIO cable to
the SGPIO1 connector into the
SGPIO2 connector on the PIKE
riser card.
7. Remove the SATA/SAS cables
from the onboard SATA1, SATA2,
ISAS1, ISAS2, ISAS3 and ISAS4
connectors.
8. The SATA/SAS cables are tied and
labeled in four groups. Group 1
connects to HDD 1 and 2, Group 2
to HDD 3 and 4, Group 3 to HDD 5
and 6, and Group 4 to HDD 7 and
8.
