Chapter 3: Installation options
3-2
3.1
Installing friction rail kit items
Your friction rail kit package contains:
•
Two pairs of rack rails (for the rack)
•
Nut-and-bolt type screws and one pair of server latches
Nuts and screws
Front rack rails
Rear rack rails
3.1.1
Attaching the fixing latches to the server
Refer to the image below for the locations to attach the two fixing latches to the two
sides of the server with four screws.
Fixing latch
