2-21 ASUS ESC4000 G2 Series
3. Insert the PSU into the empty PSU
bay.
• The system automatically combines the two power supply modules as a
single one. The combined output power varies with input voltages. Refer to
the table below for details.
Input Voltage Max. Output Power (Watt) per PSU
100V—120Vac, 12-10A, 50-60Hz 1000W
120V—140Vac, 12-10A, 50-60Hz 1200W
180V—240Vac, 10.5-8A, 50-60Hz 1620W
• To enable the hot-swap feature (redundant mode), keep the total power
consumption of the system under the maximum output power of an
individual power supply module.
• For steady power input, use only the power cables that come with the
server system package.
