ASUS ESC4000 G2 Series 1-5
*Specifications are subject to change without notice.
Model Name ESC4000/FDR G2 ESC4000 G2
Storage
SAS
Controller
Optional:
ASUS PIKE 2008 8-port SAS 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS 6G RAID card
ASUS PIKE 2108 8-port SAS 6G H/W RAID card
HDD Bays
I = Internal
A or S will be
hot-swappable
8 x Hot-swap 3.5” HDD Bays
Networking LAN 2 x Intel 82574L Gigabit LAN + 1 x Mgmt LAN
Graphic VGA Aspeed AST2300 / 16MB
Auxiliary Storage Device Bay
(Floppy / Optical Device)
1 x slim-type Optical Device Bay
(Options: No Device / DVD-RW*)
*DVD-RW default for North America
Onboard I/O
1 x External Serial Port
3 x RJ-45 ports (1 for ASMB6)
4 x USB 2.0 ports (Front x 2, Rear x 2)
1 x Internal A Type USB Port
1 x VGA port
1 x QSFP Port -
OS Support
Windows ® Server 2008 R2
Windows ® Server 2008 R2 Enterprise
Windows ® Server 2008 Enterprise 32 / 64-bit
Windows ® Server 2003 R2 Enterprise 32 / 64-bit
RedHat ® Enterprise Linux AS5.7/6.2 32 / 64-bit
SuSE ® Linux Enterprise Server 11.2 32 / 64-bit
CentOS 5.7/6.2 32/64-bit
VMWare ESX4.1/ESXi4.1
(Subject to change without any notice)
Anti-virus Software Optional Anti-virus Software CD
Management
Solution
Out of Band
Remote
Hardware
ASMB6-iKVM for KVM-over-Internet
Software ASUS ASWM Enterprise
Dimension (HH x WW x DD) 750mm x 444mm x 88mm (2U)
Net Weight Kg (CPU, DRAM &
HDD not included)
19 Kg
Power Supply
1 + 1 Redundant 1620W (80+) Platinum Power Supply
(Following different configurations by region.)
Power Rating
Input:
1000W: 100—120 Vac, 12-10A
1200W: 120—140 Vac, 12—10A
1620W: 180—240Vac,10.5—8A
50—60Hz Class I
Environment
Operating temperature: 10°C–35°C /
Non operating temperature: -40°C–70°C
Non operating humidity: 20%–90% ( Non-condensing)
