ASUS ESC4000 G2 Series 4-3
Layout contents
Jumpers Page
1. Clear RTC RAM (CLRTC1) 4-4
2. VGA controller setting (3-pin VGA_SW1) 4-5
3. ME firmware force recovery setting (3-pin ME_EN1) 4-5
4. LAN controller setting (3-pin LAN_SW1, LAN_SW2) 4-6
5. DDR3 voltage control setting
(4-pin LVDDR3_SEL1; LVDDR3_SEL2
4-6
6. RAID configuration utility selection (3-pin RAID_SEL1) 4-8
Internal connectors Page
1. Serial ATA connectors (7-pin SATA1–2 [blue], SATA3–4 [black]) 4-8
2. ISAS connectors (7-pin ISAS1–4 [blue]) 4-9
3. USB connector (10-1 pin USB34, A-Type USB5) 4-10
4. Front fan connectors (4-pin FRNT_FAN1–7) 4-11
5. Serial General Purpose Input/Output connector (6-1 pin SGPIO1) 4-12
6. TPM connector (20-1 pin TPM1) 4-13
7. Power Supply SMBus connector (5-pin PSUSMB1) 4-13
8. SSI power connectors (20-pin PWR1, 8-pin PWR2) 4-14
9. System panel connector (20-pin PANEL1) 4-15
10. Auxiliary panel connector (20-pin AUX_PANEL1) 4-16
